The geopoint question type captures geographic coordinates (latitude, longitude, altitude, accuracy) using the device GPS. rtSurvey renders the picker with several layout modes and supports automation through inputs{} and outputs{} parameters.

Basic XLSForm Specification

For the standard specification see the XLSForm documentation (opens in a new tab).

Data Format

Stored as four space-separated values:

latitude longitude altitude accuracy

Example: 13.756331 100.501762 15 8

Layout modes

Default — rectangular button

A rectangular "START GEOPOINT" button opens a full map modal where the enumerator selects a point. After capture, the button label changes to "View or change geo point" and coordinates appear below.

No appearance value required.

display{inline-icon} — circular crosshairs button

Renders a circular icon button (crosshairs ⊕) instead of the rectangular button. Tapping it opens the same map modal.

display{inline-icon}

Combined with position and size:

display{inline-icon, left}           → button left of label
display{inline-icon, top}            → button above label
display{inline-icon, bottom}         → button below label, centered
display{inline-icon, large}          → large icon (75px)
display{inline-icon, medium}         → medium icon (50px)
display{inline-icon, left, large}    → large button on the left

display{thumbnail-square} — live map thumbnail

Renders a live map preview (Leaflet) directly on the question instead of a button. The thumbnail shows the current GPS position and the selected point. Tapping the expand button opens the full modal.

display{thumbnail-square}

Custom thumbnail size:

display{thumbnail-square-[WxH]}          → fixed pixels
display{thumbnail-square-[400x200]}      → 400px wide × 200px tall

display{thumbnail-square-[W%xH%]}        → percentage of form width
display{thumbnail-square-[100%x30%]}     → full width × 30% of form width

display{} vs results{} — before and after capture

display{} controls layout before the user captures a location. results{} controls layout after a value exists. They can have different alignments.

display{inline-icon, right} results{left}

This renders the button on the right before capture, then moves it to the left once a point is recorded.

hide(value) — suppress coordinates display

By default, the captured lat/lon/accuracy/altitude text is shown below the button. Hide it with:

results{hide(value)}
display{inline-icon} results{hide(value)}

inputs{} — GPS automation

Auto-capture on load

Automatically records the GPS position when the form loads, without the enumerator pressing anything.

inputs{auto-take}

Conditional auto-capture using an XLSForm expression:

inputs{autotakeGeo(expression(if(${capture_now} = 'yes', true(), false())))}

Pre-fill from a text field

Populate the geopoint from a question that contains a place name or address string. rtSurvey reverse-geocodes the string to coordinates via OpenStreetMap Nominatim.

inputs{question(address_field)}

outputs{} — reverse geocode to text

After a point is captured, automatically populate a text question with the human-readable address (reverse geocoded from the coordinates).

outputs{question(address_field)}

Example:

nomap — GPS capture without map

Replaces the map modal with a simple dialog that requests location permission and records coordinates. No map is displayed. Useful for GPS-only capture on low-end devices or when map tiles are unavailable offline.

nomap

Custom button style

Use styleButton() to apply custom CSS to the default rectangular button:

styleButton({"backgroundColor":"#1976D2","color":"#ffffff","borderRadius":"8px"})

Suppress the label

text-nolabel display{inline-icon, center, large}

Example usage

Best Practices

1. Use inputs{auto-take} for enumerator-verification surveys where GPS is mandatory — it removes the manual step.
2. Use display{thumbnail-square} when you want the enumerator to visually confirm the selected point before proceeding.
3. Pair outputs{question(...)} with a read-only text field to show the reverse-geocoded address to the enumerator.
4. Use nomap in areas with no internet connectivity where map tiles cannot load.
5. Allow GPS time to stabilise before recording — accuracy under 10m is typically sufficient for field surveys.

Limitations

• inputs{question(name)} geocoding requires internet access — it calls the OpenStreetMap Nominatim API.
• outputs{question(name)} reverse geocoding also requires internet access.
• Map thumbnail (display{thumbnail-square}) requires internet for tile loading; coordinates are still captured offline.
• GPS accuracy varies by device and environment — indoor or urban canyon conditions may produce accuracy > 50m.
• Collecting location data may significantly impact device battery life during long surveys.
